Комутатор, Cisco Catalyst 1200 16-port GE, PoE, 2x1G SFP

  • CISCO
Комутатор, Cisco Catalyst 1200 16-port GE, PoE, 2x1G SFP
Суич, типFixed Port
Общ брой портове18
Основни портове, тип16x 10/100/1000Base-T PoE+ ports with 120W power budget
Power Over Ethernet (PoE)PoE+ (120W); 16 ports
Uplink портове2xSFP
Свободни (10GB) слотове-
УправлениеNetwork PnP, Web user interface, Cisco Business mobile app, Cisco Business Dashboard, SNMP, MIBs, RMON, DHCP, CLI and etc.
Stackable-
FansFanless
Захранване100 to 240V 50 to 60 Hz, internal, universal
RoutingLayer 3 static routing
Памет (Flash, RAM)512 MB (Flash), 1 GB DDR4 (DRAM), 1.5 MB (Packet buffer)
Капацитет за маршрутизиране/превключване, Gbps36 Gbps
Пропускателна способност, Mpps26.78 Mpps
MAC адреси8000 addresses
VLAN (брой, стандарти)Support for up to 255 active VLANs simultaneously; Port-based and 802.1Q tag-based VLANs, Management VLAN, Guest VLAN, Auto Surveillance VLAN (ASV), Voice VLAN
QoS8 hardware queues; Port based, 802.1p VLAN priority based, IPv4/v6 IP precedence/Type of Service (ToS)/DSCP based, Differentiated Services (DiffServ), classification and re-marking ACLs, trusted QoS
L2 мрежови стандартиIEEE 802.3, IEEE 802.3u/ab/ad/z/x/af/at; IEEE 802.1D (STP)/1Q/p VLAN/w RSTP/s Multiple STP/X Port Access Authentication; RFC
IPv6 functionalityIPv6 host mode, IPv6 over Ethernet, Dual IPv6/IPv4 stack, IPv6 Neighbor Discovery (ND), IPv6 stateless address auto-configuration, Path MTU discovery, DAD, ICMP v6, IPv6 over IPv4 network with ISATAP
СигурностSSL, SSH, IEEE 802.1X (authenticator role): RADIUS authentication, guest VLAN, single/multiple host mode, and single/multiple sessions; STP; SCT; SSD, Trustworthy systems, Port security, Storm control, DoS prevention, ACLs
Размери (Ш, Д, В), mm268 x 297 x 44 mm
Опция за монтажRackmount
Приложениеза бизнеса
Цена
633 59 лв / €323 95
с ДДС
В Наличност
 Добави в Количката
Удължи гаранцията си
+1 година: +108 лв.
+2 години: +178 лв.
РЕЙТИНГ
ТВОЯ РЕЙТИНГ
Мнения
Улеснено Поръчване - като въведете само телефон и име:
Съгласен съм с Общите условия
Ще Ви потърсим в рамките на работния ден. Внимание: При грешен телефонен номер, нямаме начин да се свържем с Вас.
CreditCredit

Информираме Ви, че въпреки нашите усилия не можем да гарантираме, че публикуваната информация и снимки не съдържат неточности или грешки, които не могат да бъдат правно основание за претенции.
General
Device TypeSwitch - 16 ports - L3 - smart
Enclosure TypeRack-mountable
SubtypeGigabit Ethernet
Ports16 x 10/100/1000 (PoE+) + 2 x Gigabit Ethernet SFP
Power Over Ethernet (PoE)PoE+
PoE Budget120 W
PerformanceForwarding rate (64‑byte packets): 26.78 Mpps Switching capacity: 36 Gbps
CapacityMSTP instances: 8 PVST+ instances: 126 RPVST+ instances: 126 Link aggregation groups: 4 Link aggregation ports: 8 Active VLANs: 255 IGMP multicast groups: 255 IPv4 routes (static): 32 IPv4 interfaces: 16 ACL rules: 512 Priority queues: 8 Packet buffer size: 1.5 MB
MAC Address Table Size8000 entries
Jumbo Frame Support9000 bytes
Routing ProtocolIGMPv2, IGMP, static IP routing, IGMPv3, MLDv2, MLD, CIDR, MSTP, RSTP, STP, Bounjour
Remote Management ProtocolSNMP, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, SSH-2, CLI, SCP, ICMP, DHCP, RADIUS, Syslog
Encryption AlgorithmSSL
Authentication MethodRADIUS
FeaturesBOOTP support, VLAN support, IGMP snooping, DoS attack prevention, port mirroring, DiffServ support, Unicast Storm Control, SNTP support, DHCP server, reset button, Cable Diagnostics Function, fanless, LACP support, DHCP relay, Port Security, SNMP trap, DHCP client, port grouping, Storm Control, Link Aggregation, IGMP querier, VLAN mirroring, DNS client, Voice VLAN, VLAN management, LLDP-MED, Guest VLAN, ingress rate limiting, STP loop guard, EEE, TCP/UDP proxy, DSCP based CoS, loopback detection, port-based VLAN, Telnet server, Telnet client, Unknown Storm Control, IPv4 and IPv6 dual stack, Zero-Touch Deployment, cable length detection, trustworthy systems, layer 3 routing, remote firmware upgrade, ACL support, eco-friendly button, Auto Surveillance VLAN, TCP congestion, chip guard, boot integrity, time-based port operation, tag-based VLANs, WRR queuing, BSC, MSC, MSTP support, TFTP support, QoS, PVST+, SP, GARP, GVRP, ToS, SCP, SCT, SSD, UDP, DoS protection, WRR, HoL Blocking Prevention, LAG, CDP, VSDP, RPVST+, DAD, LLDP, EQS, path MTU discovery
Compliant StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az
ProcessorX ARM: 1.4 GHz
RAM1 GB DDR4 SDRAM
Flash Memory512 MB
Status IndicatorsSystem, PoE, link/activity/speed
Expansion / Connectivity
Interfaces16 x 100/1000/2.5G/5G (PoE+) RJ-45 2 x 1000Base-X SFP 1 x console RJ-45 1 x USB-C console
Power
Power DeviceInternal power supply
Voltage RequiredAC 100-240 V (50 - 60 Hz)
Miscellaneous
Included AccessoriesMounting kit, pointer card
MTBF706,983 hours
Compliant StandardsPlug and Play, FCC CFR47 Part 15, WEEE, CSA 22.2, RFC1213, RFC1493, RFC1757, RFC2674, RFC768, RFC791, RFC1157, RFC2460, RFC2011, RFC1643, RFC2012, RFC2013, UL 62368, RFC783, RFC792, RFC2863, RFC793, RFC826, RFC854, RFC2131, RFC2132, RFC1907, RFC1215, RFC2233, RFC2665, RFC951, RFC1542, RFC2618, RFC4443, RFC1981, RFC4861, RFC4862, RFC4291, RFC813, RFC879, RFC896, RFC855, RFC856, RFC858, RFC894, RFC919, RFC920, RFC922, RFC950, RFC1042, RFC1071, RFC1123, RFC1141, RFC1155, RFC1286, RFC1350, RFC1442, RFC1451, RFC1533, RFC1541, RFC1573, RFC1624, RFC1700, RFC1867, RFC2030, RFC2576, RFC2616, RFC2666, RFC2737, RFC2819, RFC3164, RFC3176, RFC3411, RFC3412, RFC3413, RFC3414, RFC3415, RFC3416, RFC4330, RFC4007, RFC3484, RFC5214, RFC4293, RFC3595
Dimensions & Weight
Width26.8 cm
Depth29.7 cm
Height4.4 cm
Weight2.38 kg
Manufacturer Warranty
Service & SupportLimited warranty - lifetime - response time: next business day Technical support - consulting - 1 year
Environmental Parameters
Min Operating Temperature-5 °C
Max Operating Temperature50 °C
Humidity Range Operating10 - 90% RH (non-condensing)
Min Storage Temperature-25 °C
Max Storage Temperature70 °C
Humidity Range Storage10 - 90% RH (non-condensing)
АтрибутСтойност
Суич, типFixed Port
Общ брой портове18
Основни портове, тип10/100/1000Base-T
Power Over Ethernet (PoE)PoE+
Свободни (10GB) слотовеNo
УправлениеYes
StackableNo
FansНе
ЗахранванеInternal
RoutingStatic
Опция за монтажRackmount
Uplink портове2xSFP
ПодкатегорияSwitches
Приложениеза бизнеса
Тегло3.00кг
